introduction Grafana Alloy

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54

controller:
  volumes:
    extra:
    - hostPath:
        path: /proc
        type: ""
      name: proc
    - hostPath:
        path: /sys
        type: ""
      name: sys
    - hostPath:
        path: /
        type: ""
      name: root

alloy:
  mounts:
    extra:
    - mountPath: /host/proc
      name: proc
      readOnly: true
    - mountPath: /host/sys
      name: sys
      readOnly: true
    - mountPath: /host/root
      mountPropagation: HostToContainer
      name: root
      readOnly: true

  configMap:
    content: |-
      // metrics
      prometheus.remote_write "default" {
        endpoint {
          url = "http://gf-stack-mimir-distributor.monitor.svc:8080/api/v1/push"
          headers = {
            "X-Scope-OrgID" = "alloy",
          }
        }
      }

      prometheus.exporter.unix "node" { }

      // Configure a prometheus.scrape component to collect unix metrics.
      prometheus.scrape "node" {
        targets    = prometheus.exporter.unix.node.targets
        forward_to = [prometheus.remote_write.default.receiver]
      }

      prometheus.scrape "pod" {
        targets    = discovery.kubernetes.pod.targets
        forward_to = [prometheus.remote_write.default.receiver]
      }

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73
74
75
76
77
78
79
80
81
82
83
84
85
86
87
88
89
90
91
92
93
94
95
96

alloy:
  mounts:
    varlog: true

  configMap:
    content: |-

      // local.file_match discovers files on the local filesystem using glob patterns and the doublestar library. It returns an array of file paths.
      local.file_match "node_logs" {
        path_targets = [{
            // Monitor syslog to scrape node-logs
            __path__  = "/var/log/syslog",
            job       = "node/syslog",
            node_name = sys.env("HOSTNAME"),
            cluster   = "local",
        }]
      }

      // loki.source.file reads log entries from files and forwards them to other loki.* components.
      // You can specify multiple loki.source.file components by giving them different labels.
      loki.source.file "node_logs" {
        targets    = local.file_match.node_logs.targets
        forward_to = [loki.write.default.receiver]
      }


      // discovery.kubernetes allows you to find scrape targets from Kubernetes resources.
      // It watches cluster state and ensures targets are continually synced with what is currently running in your cluster.
      discovery.kubernetes "pod" {
        role = "pod"
        // Restrict to pods on the node to reduce cpu & memory usage
        selectors {
          role = "pod"
          field = "spec.nodeName=" + coalesce(sys.env("HOSTNAME"), constants.hostname)
        }
      }

      // discovery.relabel rewrites the label set of the input targets by applying one or more relabeling rules.
      // If no rules are defined, then the input targets are exported as-is.
      discovery.relabel "pod_logs" {
        targets = discovery.kubernetes.pod.targets

        // Label creation - "namespace" field from "__meta_kubernetes_namespace"
        rule {
          source_labels = ["__meta_kubernetes_namespace"]
          action = "replace"
          target_label = "namespace"
        }

        // Label creation - "pod" field from "__meta_kubernetes_pod_name"
        rule {
          source_labels = ["__meta_kubernetes_pod_name"]
          action = "replace"
          target_label = "pod"
        }

        // Label creation - "container" field from "__meta_kubernetes_pod_container_name"
        rule {
          source_labels = ["__meta_kubernetes_pod_container_name"]
          action = "replace"
          target_label = "container"
        }

        // Label creation -  "app" field from "__meta_kubernetes_pod_label_app_kubernetes_io_name"
        rule {
          source_labels = ["__meta_kubernetes_pod_label_app_kubernetes_io_name"]
          action = "replace"
          target_label = "app"
        }

      }

      // loki.source.kubernetes tails logs from Kubernetes containers using the Kubernetes API.
      loki.source.kubernetes "pod_logs" {
        targets    = discovery.relabel.pod_logs.output
        forward_to = [loki.process.pod_logs.receiver]
      }

      // loki.process receives log entries from other Loki components, applies one or more processing stages,
      // and forwards the results to the list of receivers in the component's arguments.
      loki.process "pod_logs" {
        stage.static_labels {
            values = {
              cluster = "laterstack",
              job = "alloy",
            }
        }
        forward_to = [loki.write.default.receiver]
      }

      loki.write "default" {
        endpoint {
          url = "http://loki-write.monitor.svc:3100/loki/api/v1/push"
          tenant_id = "alloy"
        }
      }
